CNC machining and additive manufacturing are complementary tools in a modern production stack. The right choice depends on tolerance bands, geometry, material pedigree, and the speed at which engineering teams need to iterate. This guide distills how we evaluate both pathways at Forge Labs so you can select the process that delivers the correct part on the first build.
How Each Process Works
CNC Machining
Computer numerical control (CNC) machining is subtractive. Material is removed from billet, bar, or plate to reveal finished geometry. Precision comes from rigid fixturing, purpose-built tooling, and toolpaths that are dialed in for every feature. Setup can be intensive, but once the program is locked, part-to-part repeatability is outstanding. Machined parts retain the isotropic properties of their parent stock.
Forge Labs partners with certified machine shops for 3-axis through 5-axis milling, turning, and secondary finishing. We engage CNC when a project demands tight tolerances, performance-critical mating surfaces, or production volumes where amortizing setup has a clear ROI.
Industrial 3D Printing
Additive manufacturing (AM) builds parts layer by layer directly from CAD. Powder bed fusion, stereolithography, fused filament fabrication, and other processes make it possible to realize internal channels, lattice infill, and organic shapes without tooling. Setup is minimal; lead time is driven by machine availability, build height, and post-processing.
Our AM fleet covers polymer SLS and SLA for functional housings and optical prototypes, high-temperature FDM for engineering thermoplastics, and DMLS for fully dense metal components. For production programs, we often print near-net geometry and machine critical datums afterwards.
Quick Comparison at a Glance
| Category | 3D Printing (Industrial AM) | CNC Machining |
|---|---|---|
| Geometry Freedom | Excels at internal channels, conformal cooling, lattices, organic forms. | Limited by tool access and undercuts; multi-axis mitigates but enclosed features require assembly. |
| Material Portfolio | Engineering polymers (PA12, PA11, TPU, high-temp resins) and metals (aluminum, stainless, Inconel). | Virtually any machinable stock: metals, plastics, composites with certified pedigree. |
| Tolerances | +/-0.1-0.3 mm typical in polymers, +/-0.05-0.2 mm in metal AM prior to finishing. | +/-0.025-0.125 mm standard; tighter bands achievable on critical features. |
| Lead Time | Minimal setup, fast to first article; cycle time scales with build height and volume. | Higher upfront programming and fixturing; fast, repeatable production once dialed in. |
| Cost Drivers | Machine time, material volume, support removal, finishing. Complexity is effectively free. | Setup, tooling, cycle time, and scrap rates. Simple or repeat geometry scales efficiently. |
Material and Performance Considerations
Material selection is often the first decision gate. AM delivers certified nylons, photopolymers, thermoplastics, and specialty metals, each with defined processing windows. CNC covers the full palette of aerospace alloys, engineering plastics, and mixed-material assemblies because strength comes from stock pedigree rather than process parameters.
Mechanical Implications
- Isotropy: CNC retains isotropic stock properties. AM polymers display directional strength and must be oriented thoughtfully.
- Thermal Performance: Metal AM withstands high temperatures after stress relief and HIP; CNC still dominates extreme fatigue or legacy qualification programs.
- Surface Finish: Machining produces sealing surfaces straight off the tool. Additive parts require blasting, coating, or secondary machining for cosmetic or sealing faces.
Cost, Lead Time, and Scaling
Additive manufacturing keeps tooling out of the equation. That makes low-volume runs, rapid iteration, and serialized custom parts cost-effective. CNC has more upfront work, but when your product roadmap calls for dozens or hundreds of repeat builds, amortizing setup yields the lowest unit cost and tightest control over dimensional variance.
In practice, Forge Labs evaluates total landed cost: machine hours, finishing, inspection, logistics, and risk. The economics often trend toward AM for prototype through bridge production, and CNC for validated geometry at scale. The crossover point depends on tolerance bands and whether geometry requires multi-step fixturing.
When to Choose Each Path
Bias Toward 3D Printing When
- You need internal channels, lattice cores, or organic ergonomics.
- Designs will iterate multiple times before locking production intent.
- Low-volume or serialized components demand rapid turns without tooling.
- Weight reduction, part consolidation, or mass customization drives value.
Bias Toward CNC When
- Critical features require +/-0.025 mm tolerances, mirror finishes, or gauged fits.
- You are ramping to 50-5,000 pieces and want predictable unit cost.
- Material pedigree, certifications, or fatigue performance are non-negotiable.
- The geometry is prismatic or easily accessible with standard tooling.
Hybrid Workflows at Forge Labs
Our team frequently combines both processes. We print near-net geometry to capture complex internal features, then finish critical faces, bores, and datums on CNC equipment. This shortens lead time, reduces waste, and keeps tight tolerances where they matter. Hybrid builds also simplify qualification because additive manages the complexity while machining preserves legacy inspection steps.
Typical Hybrid Steps
- Design for additive to capture internal channels, then define machining stock allowances on critical faces.
- Print production-intent builds with traceable material lots and controlled orientation.
- CNC finish datums, threads, and sealing surfaces, followed by inspection and documentation.
Implementation Checklist
| Question | Why It Matters | Forge Labs Guidance |
|---|---|---|
| What is the tightest tolerance on the drawing? | Determines whether additive alone is viable or if post-machining is mandatory. | Flag any feature tighter than +/-0.1 mm during RFQ so we can stage hybrid operations. |
| How will the part be finished? | Surface finish impacts sealing, cosmetics, and downstream coating. | Specify Ra or cosmetic class early; we align blasting, tumbling, or machining accordingly. |
| What is the production horizon? | Economics shift between prototype, bridge builds, and full-rate production. | We model total landed cost across AM, CNC, and hybrid scenarios to prevent surprises. |
| Are there certification or traceability requirements? | Material pedigree and documentation can limit process options. | We maintain lot traceability for AM powders and leverage vetted CNC partners for certified programs. |
Example Scenarios
- Thermal management bracket: Print the complex internal cooling path in SLS PA12, then machine sealing faces and datum bores.
- Transparent control enclosure: SLA clear resin for rapid UX iterations; transition to CNC polycarbonate once geometry is frozen.
- Production aluminum mount: Validate the design with additive prototypes, then move to CNC with dedicated fixturing for 500+ pieces.
How Forge Labs Engages
Whether you bring a single prototype or a production-intent assembly, we evaluate the part holistically. Share the CAD, tolerance stack, and performance targets. We will recommend additive, subtractive, or a hybrid route and map inspection, finishing, and documentation so you know exactly how the part will land.
Ready to Evaluate Your Part?
Submit your CAD package and requirements. Our manufacturing engineers will identify the right process mix, provide a transparent quote, and outline the path to first article approval.
